Developing Underworld using Python Virtual Environments

The Underworld Community has been supporting usage of Docker containers for developing and running Underworld powered scientific models. They provide a good option to control the running environment (dependencies).

Docker container can be used for developing the code base but creating a suitable development workflow has proven challenging so far and I have opted for a more simple solution involving native builds of PETSc and Python Virtual Environment.

In the following I describe how I install Underworld (v2.12) in a Python virtual environment. This is by no way perfect and others may have a different approach, I always welcome suggestions!


The main dependency that we use is PETSc (the Portable, Extensible Toolkit for Scientific Computation). PETSc installation is not complicated but can be time-consuming depending on how many External Packages (Solvers etc.) are required. I suggest reading my other blogpost to learn what's needed and how to install PETSc on your machine.

PETSc tends to evolve quite fast and we thus need to make sure that we keep up to date with the changes introduced with each new version. We also need to be able to test for some sort of back-compatibility.
My solution to this problem has been to compile different versions and configuration of PETSc on my machine. They are all located in the /opt directory and I can switch easily between versions as needed.

Here is a snapshot of my /opt/ directory:

3.13.6  3.14.6  3.15.5  3.16.1

Python Virtual Environment

Python Virtual Environment provide an easy way to control your python packages stack. It is not the only way to achieve this, some other tools such as Conda and Module files can do the same thing and actually extend the idea to other non-python-based applications.
So here again all roads lead to Rome and you just need to find what works for you.

To use virtual environments you first need to install the appropriate package on your machine. Note that it is good practice to use the package provided by your LINUX distribution.

On Arch Linux we use:

sudo pacman -Syy
sudo pacman -S python-virtualenv

on Ubuntu

sudo apt-get update
sudo apt-get install -y python3-venv

Virtual Environment are created using:

python -m venv --name my_underworld_env

The virtual environment is then activated by sourcing the activate script as follow:

source my_underworld_env/bin/activate

Handling PETSc

The activate script that you source when activating a Python virtual environment contains a set of instructions that set the PATH and  PYTHONHOME environment variables.
The trick to handle PETSc is to also let the activate script to manage the PETSC_DIR environment variable. The PETSC_DIR variable should point to the PETSc version you want to use with the Python virtual environment.

In the following I am modifying the script so that it creates:

  • PETSC_DIR (that points to the PETSc built I want to use)
  • PYTHONPATH (points to $PETSC_DIR/lib )
  • PATH (points to $PETSC_DIR/bin where I have mpirun etc.)

I also modify the deactivate function so that variables are reset when we deactivate the virtual environment.

# This file must be used with "source bin/activate" *from bash*
# you cannot run it directly

deactivate () {
    # reset old environment variables
    if [ -n "${_OLD_VIRTUAL_PATH:-}" ] ; then
        export PATH
        unset _OLD_VIRTUAL_PATH
    if [ -n "${_OLD_VIRTUAL_PYTHONHOME:-}" ] ; then
        export PYTHONHOME
    if [ -n "${_OLD_PYTHONPATH:-}" ] ; then
        export PYTHONPATH
        unset _OLD_PYTHONPATH
    if [ -n "${_OLD_PETSC_DIR:-}" ] ; then
        export PETSC_DIR
        unset _OLD_PETSC_DIR

    # This should detect bash and zsh, which have a hash command that must
    # be called to get it to forget past commands.  Without forgetting
    # past commands the $PATH changes we made may not be respected
    if [ -n "${BASH:-}" -o -n "${ZSH_VERSION:-}" ] ; then
        hash -r 2> /dev/null

    if [ -n "${_OLD_VIRTUAL_PS1:-}" ] ; then
        export PS1
        unset _OLD_VIRTUAL_PS1

    unset VIRTUAL_ENV
    if [ ! "${1:-}" = "nondestructive" ] ; then
    # Self destruct!
        unset -f deactivate

# unset irrelevant variables
deactivate nondestructive


export PATH

# unset PYTHONHOME if set
# this will fail if PYTHONHOME is set to the empty string (which is bad anyway)
# could use `if (set -u; : $PYTHONHOME) ;` in bash
if [ -n "${PYTHONHOME:-}" ] ; then
    unset PYTHONHOME

if [ -z "${VIRTUAL_ENV_DISABLE_PROMPT:-}" ] ; then
    PS1="(uw2_venv) ${PS1:-}"
    export PS1

# This should detect bash and zsh, which have a hash command that must
# be called to get it to forget past commands.  Without forgetting
# past commands the $PATH changes we made may not be respected
if [ -n "${BASH:-}" -o -n "${ZSH_VERSION:-}" ] ; then
    hash -r 2> /dev/null


export PETSC_DIR

Now sourcing the activate script sets PETSC_DIR PATH and PYTHONPATH to the appropriate values. Running deactivate takes us back to normal. We are ready to install Underworld and the python packages we need!

Installing Underworld in development mode

Underworld requires some building dependencies.


apt-get update -qq
apt-get install \
        build-essential \
        pkg-config \
        python3-dev \
        cmake \
        make \
        swig \
        libxml2-dev \

Installing h5py

After activating the Python virtual Environment so that the install process uses the appropriate version og HDF5 and H5PCC

source my_underworld_venv/bin/activate

CC=h5pcc HDF5_MPI="ON" HDF5_DIR=${PETSC_DIR} pip3 install --no-cache-dir --no-binary=h5py git+

Get the current development branch of Underworld from GitHub

source my_underworld_venv/bin/activate

git clone
cd underworld2
git checkout development

Then build Underworld

# From the underworld directory
pip install -vvv -e .

You should now have a Python virtual environment with a working version of Underworld


Python Virtual Environment can be useful for Underworld development. You can easily configure them so that they  point to a specific version of PETSc on your machine.
This make possible to test the code against different versions of PETSc, run tests and try different optimization options or configurations of the software stack.
